3-D Woven Composites: Characteristics & Uses

Utilizing 3-D woven composite structures in place of traditional metal or 2-D laminated composites can provide cost savings through both the manufacturing process and a product’s operational lifetime. In this blog, we’ll answer some basic questions about the emerging technology – and why it’s useful for a wide variety of applications

3D composite structure by BRM



What allows 3-D weaving to produce strong, complex, single-piece structures?

Most fabrics are woven in two dimensions – the X axis (length) and the Y axis (width) – but 3-D woven fabrics include weaving through the thickness, or the Z axis. By contrast, 2-D composites include a number of different layers of materials artificially bonded together; these layers can come apart from each other, or delaminate. 3-D weaving produces near-net-shape composite structures that are fully interconnected by their yarn, ensuring they retain strength and reliability.

What are some of the benefits of 3-D woven composites?

In addition to the elimination of delamination, the technology’s key benefits include weight reduction, reduced crack risk, lower production time, and cost reduction.

Lightweight. 3-D woven composites are dramatically lighter than metal structures. This is particularly relevant to the aerospace industry. Every pound of weight saved from an aircraft is estimated to save the aircraft’s operator roughly $1 million in operating expenses, primarily fuel, over that aircraft’s lifetime. Smart utilization of 3-D woven composite structures in aircraft design can reduce the weight of an aircraft by up to 30 percent, resulting in considerable operational cost savings.

Low crack risk. Due to curvature limitations in the layers, many 2-D shapes have considerable gaps in joints and intersections. These spaces and pockets are often filled with resin, which can crack. 3-D woven composites, even in complex shapes, have no empty pockets, as their structural integrity extends along all three axes. Crack rates are therefore far lower.

Quick production. 2-D composite production entails a long plying process. By contrast, 3-D weaving of composite structures is simpler, faster, and more cost efficient. The difference in a 3-D loom is that weft and warp yarns are not only woven together on one plane, but one plane is woven together with the next. Aside from designing a 3-D weave, which requires highly skilled design engineers, the 3-D weaving process is fully automated, drastically reducing manufacturing time.

Low cost. Indirect cost savings result from operational cost savings, for example reduced fuel. Plus, 3-D woven composites are stronger, more resilient, and less prone to breakage than 2-D laminated composites, so they can be replaced much less often, reducing replacement and maintenance costs.

What are some uses for 3-D woven structures?

3-D woven composites including orthogonal panels, thermal protection systems, near-net-shape, and complex net shape preforms are used for the aerospace, automotive, construction, military, and safety industries. For example, carbon fiber composites replace traditional titanium components in large aircraft engines to reduce weight, as these composite components are significantly lighter than comparable components in metal.

3-D weaving has been particularly successful in advancing aviation heat shield technology. BRM has woven quartz compression pads for NASA’s Orion capsule in order to ensure structural strength during launch and heat resistance during re-entry. NASA’s Heatshield for Extreme Entry Environment Technology (HEEET) program is developing a carbon thermal protection system (TPS) for extreme entries, intended to be capable of surviving the challenging environments of Saturn or Venus.

By Mark Harries

For more information about 3-D woven composites, and how they could improve your design, contact BRM today.

Bally Ribbon Mills embraces Six Sigma Methodology

Bally Ribbon Mills has effectively embraced the Six Sigma methodology for improved productivity, efficiency and cost savings which allows us to better serve the needs of our customers

3.4

The central principle of Six Sigma is that data can be used to drive manufacturing to achieve at least six standard deviations between the mean and the nearest specification limit; in other words, to produce no more than 3.4 defects outside of customer specifications in each one million products.

1

Given the highly critical nature of BRM’s products, we deliver quality to meet industry standards including ISO 9001, AS 9100, and ISO 13485, plus MIL-I-45208 and MIL-Q-9858 for military products. We began experimenting with Six Sigma (6∑) by sending one employee for training. As a direct result, that individual worked on a project that saw a 77% decrease in waste in the production of a single item, and BRM chose to implement the methodology throughout our manufacturing.

 30%

After an additional two employees were trained as Six Sigma Black Belts, the company saw a 30% reduction in overall waste during the first two years of the program. We then decided to expand the program with training for additional team members, allowing us to distribute trained individuals across functional areas and industry focuses, so that the quality assurance (QA) program has both a broader impact across the company and a more targeted impact within individual sectors. Currently, BRM is training and adding more certified persons each year to the program.

 92%

The greatest impact of implementing 6∑ methodology has been the improvements in data collection and analysis. Using 6∑ statistical tools and methodology, our well-trained QA team can use the same data that most manufacturing facilities already collect and get to a better confidence level, lower material use, less waste, lower lead times, and reduced overproduction compared with other QA methodologies. Now, the QA teams work alongside the design and manufacturing teams to design new machine setups and more precise production from the very beginning. One project has reduced rejections by 80%, and another reduced the internal rejection rate by 92%.

Customer Impact

The 6∑ methodology had provided both BRM and our customers with better tools to work together while using the same language for goals and the process of achieving them. Customers are now able to discuss product developments via electronic communications, as our experts work on product development and quality management.

Additionally, the 6∑ QA efforts have reduced cost for customers due to greater manufacturing efficiency and greater confidence in tolerances such as thickness, weight, and tensile strength. 6∑ methodology has also enabled some BRM customers to achieve tighter tolerances for materials and design. BRM customers can have greater confidence in the products they receive from initial production runs, and can thus design their final products to be closer to their ultimate goals.



To learn more about BRM’s quality assurance and how it can benefit your product, contact us.







BRM Celebrates Success of HEEET Collaboration with NASA

“I think some of the NASA approach and mindset started to rub off on us, and we started to push what we could do even further into other projects.”

Bally Ribbon Mills’ Mark Harries recently spoke at NASA’s Ames Research Center in celebration of the Heatshield for Extreme Entry Environment Technology team of NASA and BRM scientists and their exceptional accomplishments over the last ten years. His remarks offer a helpful lens for understanding BRM’s dedication to innovation:

“The first meeting I ever attended with [NASA Ames Research Center engineer] Raj Venkatapathy and the Ames group was in 2010. I remember this meeting well, and tried to think about why this meeting stood out in my mind—I had been to many customer visits and sales calls—and I finally figured out what made this one so special. It was the extraordinary level of excitement and energy surrounding the whole meeting. From beginning to end, our engineers and the NASA engineers exchanged ideas. We realized, even at that early stage, that we had both found a great partner. The Ames group was excited because of our capabilities and past experience with complex highly technical weaving, and we were excited to embark on developing new technologies and ideas that had never been developed before, including finished parts, weaving techniques, and a new loom.

That first meeting went well, and honestly, the meetings kept going well. Here we are almost ten years later celebrating the HEEET program. And what an exciting 10 years it has been. We’ve learned a great deal about woven thermal protection systems (TPS) since the start.

There has been a lot of learning. We had made panels and 3D weaves before, and I think that’s what generated the initial interest in our company, but what the Ames group was asking for with the HEEET program went above and beyond anything else in our experience to that time.

The scale of everything was bigger than anything we had attempted up until that point. The loom was bigger. The amount of yarn and number of ends (or yarn per inch of material) was incredible. For example, the first iteration had a total of 25,000 ends to weave and interconnect and keep consistent tensions with. So, the loom needed to be specially designed to handle the complex and dense material. The loom is one of a kind in the world. And because science doesn’t stop at just good enough… we got even more complex. On the most current revision of HEEET, we weave 36,000 ends. It has two main parts, one for recession and the other for insulation and protection. On both sides, NASA and the Bally Ribbon Mills teams tackled each hurdle and ultimately were successful.

There were ups and downs and some big challenges. And we are so happy that we tackled those problems.  After each issue, whether related to yarn, machinery and equipment, or programming, we learned and catalogued and anticipated the next course of action. I think some of the NASA approach and mindset started to rub off on us, and we started to push what we could do even further into other projects. For me, as a small business owner, this is the most valuable result of our partnership with NASA. We pushed ourselves. We made things that we would have never been able to otherwise and as a result of that partnership, we are seeing great returns on that investment, because these products aren’t just useful for one application. There are commercial and government entities buying products as a direct result of our work and the advancement of our capabilities.

Our history with NASA is a long one. We’ve made parts for many missions including webbing for the deceleration systems on the mars rovers. When [Former astronaut and NASA Administrator] Charlie Bolden was at BRM in 2015, he gave us a terrific tag line: “the path to Mars goes through Bally, Pennsylvania.” And with HEEET, we want it to come back again too with the Mars Sample Return Mission!”
